Description

Dimensions 11″ x 8-1/2″ x 1-1/2″More Efficient than Ordinary Tube and Fin CoolersLarger Size for High Performance ApplicationsStronger and More Resistant To DamageAccepts 1/2-inch NPT Male FittingsRugged Stacked-Plate DesignPolished Show Car FinishOur B&M Hi-Tek SuperCoolers feature a stacked plate design which is up to 30% more efficient than tube and fin designs and have 15% less flow restriction resulting in maximum cooling efficiency. The cooler features built-in attachment points, making mounting the cooler a breeze and the cooler is suitable for many fluids including transmission fluids, engine oil, and power steering fluid. This large polished SuperCooler has a BTU rating of 20,500 BTU’s. The hose fitting size for this cooler is 1/2-inch NPT and can be mounted with fittings located up, down or sideways. The SuperCooler features durable brazed aluminum construction and is pressure tested to 200 PSI. This cooler is recommended for high performance vehicles, street rods and full size trucks modified 4, 6 and V8 cylinder engines.

BTU Rating: 20500 BY

Color: Polished

Core Design/Type: Stacked Plate

Core Material: Aluminum

Core Row Quantity: 40

Core Tube Width: 1.25″

Depth: 1.5″

Design Type: Stacked Plate

Electric Fan: No

Electrical Fan: No

Finish: Raw Aluminum

Grade Type: Performance

Height: 8

Inlet Attachment Type: Female Threads

Inlet Diameter: 1/2 NPT”

Inlet Size: 1/2 NPT”

Item Grade: Performance

Length: 10″

Line Included: No

Line Inside Diameter: 0.375″

Material: Aluminum

Mounting Hardware Included: No

Outlet Attachment Type: Female Threads

Outlet Diameter: 1/2 NPT Inch

Outlet Size: 1/2 NPT Inch

Pressure Test: 200 psi

Row Quanity: 40

Strap Included: No

Thickness: 1.5 Inch

Universal/Direct-fit: Universal

Width: 11
